TABLE OF CONTENTS
SECTION 2
802.3 INTERFACE (CONT.)
Page
2.2 SETr:NGS .............................................................................. 2-3
2.3 CONTROLS AND INDICATORS .. ...... .... .. .... .... ...... ...... .... ...... .... 2-4
2.4 TROUBLESHOOTING ............................................................... 2-7
2.4.1 Requirements ............................................................... 2-7
2.4.2 User Self Diagnostics Description ................................. 2-8
2.4.3 Running 3C505.EXE Program .............. ..... .................. 2-12
2.4.4 Procedure When Loopback Test Fails .......................... 2-15
2.5 INSTALLATION ...................................................................... 2-16
2.5.1 Unpacking Interface Board .......................................... 2-16
2. 5. 2 Accessing Option Board Slot .. .. .. . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 2-17
2.5.3 Jumper Setting Check ... ...... ................ ..... .......... ..... . .. 2-18
2.5.4 Setting OMA Channel Jumpers .. .... .... .. ..... .................. 2-19
2.5.5 Setting Interrupt Channel Jumpers ............................. 2-20
2.5.6 Setting 1/0 Base Address Jumpers ............................ 2-21
2.5.7 Setting Transceiver Select Jumpers .... ...... .... .... ...... . .. 2-22
2.5.8 Setting ROM Select Jumpers .... .......... .... .. ......... ...... .. 2-23
2.5.9 Mounting Interface Board in PC .................................. 2-24
2.5.10 Installing Adapter Plate .............................................. 2-25
2.5.11 Testing Interface Board .. .... .. .. .. .. . .. .. .. .. .. .. .. .. .. .. .. .. .... .. . 2-26
