B-1
B Specifications
This appendix provides the following types of specifications for the 515 pump:
•Physical
• Environmental
• Electrical
• Performance
• Instrument control and communication.
Physical specifications
Item Specification
Height
Depth
Width
Weight
8.0 in. (20.3 cm)
18.5 in. (47 cm)
7.5 in. (19.1 cm)
33 lb (15 kg)
Wetted surface
material
316 stainless steel, sapphire, reinforced fluorocarbon
polymer seals, carbon-reinforced Tefzel
Environmental specifications
Item Specification
Operating temperature 4 to 40 °C
Humidity 20 to 80%, noncondensing
Audible noise <70 dB(A) at operator position
Solvent compatibility Solvents consistent with materials of construction.
Salts and buffers can reduce seal life, especially at
pressures in excess of 3000 psi.
Electrical specifications
Item Specification
Power requirements 110 VA (max), 55 VA (typical)
