3-4 Using the Waters 515 Pump
Keypad
The table below describes the functions of the keys on the 515 pump keypad.
Keypad functions
Key Function
Local mode: If the unit is not pumping, pressing this
key starts the pump using all current parameter
settings.
*
Remote mode: If the unit is not pumping, pressing
this key prepares the pump to receive a remote run
command.
In Local or Remote mode, pressing this key
immediately stops the pump.
*
Refer to the Mode parameter in the table titled “515
pump operating parameters” on page 3-7 for details
about Local and Rem parameters.
When pressed the first time, this key positions the
blinking cursor in the currently displayed menu item.
Pressing this key with the Flow parameter displayed,
results in one of the following events:
• The blinking cursor moves one position to the
right.
• If the cursor is at the rightmost position, it moves
to the leftmost position.
When editing in the Calibrate menu:
*
• Press the key twice to enter the submenu.
• At the submenu level, press the key to store a
parameter or initiate an action.
• When you are prompted, press the key to exit the
Calibrate menu.
*
The LCD display provides prompts for when to use
the Edit/Enter key while editing in the Calibrate
menu. See the table titled “515 pump operating
parameters” on page 3-7 for more information about
the Calibrate menu.
