Electronics components 1-5
Pump electronics components
Electronics components
Component Function
Cooling fan vent Exhausts air for cooling internal electronics.
External controller
connector
Provides connection for the pump control cable,
which connects the pump to an external control
device.
TP01409
TP01407
Front and side views
Power switch
Keypad and
LCD display
Cooling fan vent
External controller
connector
Power entry module
Rear view
