For example, the figure below illustrates a three-pump configuration under
the control of a Millennium
32
Chromatography Manager workstation.
Three-pump configuration under Millennium
32
Chromatography Manager
control (using the PCM)
Chromatography
Manager
Millennium
32
Pump Control Module
(PCM)
Pump
A
Pump
Pump
B
C
Pump control
cables
IEEE-488 connector
IEEE-488 cable
