The following table describes the items in the binary solvent manager control
panel:
You can access these additional functions by right-clicking anywhere in the
binary solvent manager control panel:
Binary solvent manager control panel items:
Control panel item Description
Flow LED Displays the actual flow LED on the front
panel of the binary solvent manager unless
communications with the binary solvent
manager are lost.
Status Displays the status of the current operation.
System Pressure Displays system pressure, in kPa, bar, or psi.
You can customize pressure units via the
ACQUITY UPLC Console.
Flow Rate Displays the total flow rate of the binary
solvent manager, from 0.000 to 2.000 mL/min
under normal operation and 0.000 to 8.000
mL/min when priming.
Solvent Composition Displays the percentage of solvent to be
drawn from the solvent lines (A and B).
Composition values range from 0.0 to
100.0%.
(Stop Flow)
Immediately stops all flow from the binary
solvent manager.
