Environmental specifications
July 7, 2014, 715003736IVD Rev. C 63
TQ-S mass spectrometer
The following table lists the physical specifications for the Xevo TQ-S mass
spectrometer:
Environmental specifications
The following table lists the environmental specifications for the ACQUITY
UPLC I-Class IVD system:
CH-A physical specifications:
Attribute Specification
Height 71.1 cm (28 inches)
Width 61.0 cm (24 inches)
Length 99.5 cm (39 inches)
Weight, with two scroll
pumps
352 kg (777 pounds)
Weight, with two
rotary pumps
408 kg (899 pounds)
Warning: To prevent inaccurate results, do not operate the instrument
outside the operating temperature and humidity specified.
ACQUITY UPLC I-Class IVD system environmental specifications:
Attribute Specification
Acoustic noise <65 dBA, system: binary solvent
manager, sample manager
(SM-FTN), CH-A
Operating temperature 15 to 28°C (59 to 82 °F)
Short-term (1.5 h) variations
must be no more than ±2 °C
(3.5 °F)
Operating humidity 20 to 80%, noncondensing
Shipping and storage temperature 0 to 40 °C
Shipping and storage humidity 20 to 80%, noncondensing
