July 7, 2014, 715003736IVD Rev. C 91
E FlexCart Assembly
Assembling the FlexCart
If your system includes the optional FlexCart, follow the procedure below to
unpack and assemble it.
Recommendation: Because the assembled system weighs at least 140.6 kg,
Waters recommends that you assemble the instruments and components on
the FlexCart.
To assemble the FlexCart
1. Remove the contents from the box packaged in the FlexCart.
Tip: The box contains the monitor arm, the bolts used to attach the
monitor arm to the base, and an IBM instruction book for converting the
monitor from stand-alone to arm-mounted.
Contents:
Topic Page
Assembling the FlexCart ................................................................. 91
Adjusting the FlexCart’s height ...................................................... 93
Locking the FlexCart in place ......................................................... 94
Moving the assembled FlexCart...................................................... 95
