Waters ACQUITY UPLC I-Class IVD - Specifications

Physical specifications
July 7, 2014, 715003736IVD Rev. C 61
B Specifications
These system specifications depend on the conditions in individual
laboratories. Refer to the ACQUITY UPLC I-Class (IVD) System Site
Preparation Guide (part number 715003724), or contact Waters
Technical Service for details.
Note: For specifications on the mass spectrometer, see the Xevo TQ-S
IVD Mass Spectrometry System Operator’s Overview and Maintenance
Guide.
Physical specifications
Binary solvent manager
The following table lists the physical specifications for the ACQUITY UPLC
I-Class IVD BSM:
Contents:
Topic Page
Physical specifications 61
Environmental specifications 63
The following table lists the environmental specifications for the
ACQUITY UPLC I-Class IVD system: 63
Wetted materials of construction 67
BSM physical specifications:
Attribute Specification
Height 22.9 cm (9.0 inches)
Width 34.3 cm (13.5 inches)
Depth 66.0 cm (26.0 inches)
Weight 26.3 kg (58.0 pounds)
