Sample manager - FTN input/output specifications
The following table lists the input/output specifications for the ACQUITY
UPLC I-Class IVD SM - FTN:
Auxiliary input 1 TTL signal or contact closure:
Input voltage range: ±30 VDC
Logic High: ≥3.0 VDC
Logic Low: ≤1.9 VDC
Minimum pulse width: 100 msec
Screw terminal connector
Auxiliary input 2 TTL signal or contact closure:
Input voltage range: ±30 VDC
Logic High: ≥3.0 VDC
Logic Low: ≤1.9 VDC
Minimum pulse width: 100 msec
Screw terminal connector
Analog outputs (1 and
2)
0 to 2 volts full scale, screw terminal (digital to
analog converter range is -0.1 to 2.1 to allow for
offsets)
Sample manager - FTN input/output specifications:
Attribute Specification
Event output relay
(Inject Start Out)
Maximum voltage: 30 VDC
Maximum current: 0.5 A
Contact resistance (nominal): 0.2 ohms
Digital input signal
(Inject Hold In)
Maximum input voltage: 30 VDC
Logic High: ≥3.0 VDC
Logic Low: ≤1.9 VDC
BSM input/output specifications: (Continued)
Attribute Specification
