External wiring connections
July 7, 2014, 715003736IVD Rev. C 71
External wiring connections
ACQUITY UPLC I-Class IVD instrument external wiring
connections
The rear panel connections for ACQUITY UPLC I-Class IVD system modules
are shown below
TP03533
Power cords
Ethernet cables
Solvent tray
Xevo TQ-S
Column heater
External power and
communications
cable (CH-A only)
Ethernet switch
Sample manager
Binary solvent
manager
Drain tube outlet
