ACQUITY control panels
July 7, 2014, 715003736IVD Rev. C 37
You can access these additional functions by right-clicking anywhere in the
sample manager control panel.
Current Column Heater
Temperature
Displays the current column heater
temperature to 0.1 °C resolution, even when
active temperature control is disabled.
Column Heater Set Point Displays the current column heater set point,
to 0.1 ° C resolution. When active
temperature control is disabled, this field
displays “Off”.
(Display Console)
Displays the ACQUITY UPLC Console.
Additional functions in the sample manager control panel:
Control panel function Description
Prime Displays the Prime dialog box.
See “Priming the SM-FTN” in the Sample
Manager - Flow Through Needle Operator’s
Overview and Maintenance Guide, (part
number 715003737IVD)
Wash needle Displays the Wash Needle dialog box.
See “Washing the SM-FTN needle” in the
Sample Manager - Flow Through Needle
Operator’s Overview and Maintenance Guide,
(part number 715003737IVD)
Reset SM Resets the sample manager following an
error condition.
Help Displays the ACQUITY UPLC Console
online Help.
Sample manager control panel items: (Continued)
Control panel item Description
