Watlow Series F4P Parameters ■ 6.13
✔ Note: For more information about how parameter set-
tings affect the controller’s operation, see the Features
Chapter.
*Not functional if analog input 3 setup for cascade.
**Scale Low value must be less than Scale High value for
Normal or Inverse Scaling.
Setup Page Parameter Table Modbus
Register
Range read/write Conditions for
Parameter Description (Modbus Value) Default (I/O, Set) Parameters to Appear
Inputs 2 and 3 appear only if
the controller is the enhanced
version (F4P _ - _ _ AB - _ _ _
_). Active: Always.
Input
603 [1]
613 [2]
623 [3]
r/w
—Depends on sensor and
decimal point selec-
tion.
(max. range process
19999 to 30000)
Set Point High Limit
*
Set limit for maximum
set point.
Inputs 2 and 3 appear only if
the controller is the enhanced
version (F4P _ - _ _ AB - _ _ _
_). Active: Always.
Input
602 [1]
612 [2]
622 [3]
r/w
—Depends on sensor and
decimal point selec-
tion.
(max. range process
19999 to 30000)
Set Point Low Limit
*
Set limit for minimum
set point.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
Active if Sensor is set to Pro-
cess.
Input
693 [1]
694 [2]
695 [3]
r/w
0Normal Scaling (0)
Scale Inversion (1)
Scaling
Set the process input
scaling relationship.
Inputs 2 and 3 appear only if
the controller is the enhanced
version (F4P _ - _ _ AB - _ _ _
_). Active if Sensor is set to
Process.
Input
681 [1]
683 [2]
685 [3]
r/w
—Depends on sensor and
decimal point selec-
tion.
(max. range -19999 to
30000, process)
Scale High
Set unit value for high
end of current or voltage
range.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
Active if Sensor is set to Pro-
cess.
Input
680 [1]
682 [2]
684 [3]
r/w
—Depends on sensor and
decimal point selec-
tion.
(max. range -19999 to
30000, process)
Scale Low
Set unit value for low
end of current or voltage
range.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
Active: Always.
Input
606 [1]
616 [2]
626 [3]
r/w
00 (0)
0.0 (1)
0.00 [process] (2)
0.000 [process] (3)
Decimal
Set the decimal point for
input.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
Active if Sensor is set to Pro-
cess.
Input
608 [1]
3070 char 1
3071 char 2
3072 char 3
618 [2]
3073 char 1
3074 char 2
3075 char 3
628 [3]
3076 char 1
3077 char 2
3078 char 3
r/w
Temperature
(0)
Temperature (0)
Units (1) [3 characters]
Units
Name the units of mea-
sure for the input.
Main > Setup > Analog Input x (1 to 3) Inputs 2 and 3 appear only if the controller is the enhanced version (F4P _ - _ _ AB - _ _ _ _).
Analog Input x (1 to 3) continued
Appears if the controller is the
enhanced version (F4P_ - _ _
AB- ____), Analog Input 2 is
selected and Analog Input 3 is
set to Normal Control.
1140 r/w
Normal
Normal (0)
Remote (3)
Alternate (4)
Control Type
Select the control type.
Main > Setup > Analog Input 2
Inputs 2 and 3 appear only if the controller is the enhanced version (F4P _ - _ _ AB - _ _ _ _).
Analog Input 2
