Watlow F4P Series

A.8 ■ Appendix Watlow Series F4P
Index
Boldface page numbers refer to parameter
entries.
å key 2.2kkk
0.000V, Calibrate, Input x (1 to 3) 6.29
0.00mV Thermocouple, Calibrate Input
x (1 to 3) 6.29
1.000V, Calibrate Output x (1A or 1B)
6.30
1.000V, Retransmit x (1 and 2) 6.30
4.000mA, Calibrate Input x (1 to 3)
6.30
4.000mA, Calibrate Output x (1A or 1B)
6.30
4.000mA, Calibrate Retransmit x (1
and 2) 6.30
10.000V, Calibrate Input x (1 to 3) 6.30
10.000V, Calibrate Output x (1A or 1B)
6.31
10.000V, Calibrate Retransmit x (1 and
2) 6.31
15.0 Ohms, Calibrate Input x (1 to 3
RTD) 6.29
15.0 Ohms, Calibrate Input 3 slidewire
6.30
20.000mA, Calibrate Input x (1 to 3)
6.30
20.000mA, Calibrate Output x (1A or
1B) 6.30
20.000mA, Calibrate Retransmit x (1
and 2) 6.30
32°F Type J, Calibrate Input x (1 to 3)
6.29
50.00mV Thermocouple, Calibrate In-
put x (1 to 3) 6.29
380.0 Ohms, Calibrate Input x (1 to 3)
6.29
1000 Ohms, Calibrate Input 3 slidewire
6.29
°F or °C 6.11
A
A to D, CJC x ( 1 to 3) 6.28
A to D, Input x ( 1 to 3) 6.28
accuracy A.2
Activate Message 6.17
active output indicator lights 2.2
Address 6.20
agency approvals A.2
alarms
clearing 3.1
deviation 3.1, 7.10
features 7.10 - 7.11
operation 3.1
process 3.1, 7.10
rate 3.1, 7.10
self-clearing 7.11
set points 7.10
troubleshooting 2.5
Alarm x (1 or 2) Condition 6.2
Alarm x (1 or 2) High Deviation 6.7
Alarm x (1 or 2) High Set Point 7.10 –
7.11, 6.6
Alarm x (1 or 2) Low Deviation 6.7
Alarm x (1 or 2) Low Set Point 7.10 –
7.11, 6.6
Alarm x (1 or 2) Maximum High Rate
6.7
Alarm x (1 or 2) Maximum Low Rate
6.7
Alarm Hysteresis 6.19, 7.10
alarm latching 7.11 — See also Latch-
ing
Alarm Logic 6.19
Alarm Messages 6.19
Alarm Name 6.19 — see also Name
alarm output indicator lights 2.2
Alarm Output x (1 and 2) Menu 6.19
Alarm Set Points 3.1, 6.6, 7.10
Alarm Set Points Menu 6.6 – 6.7
Alarm Sides 6.19, 7.11
alarm silencing 7.11 — see also Silenc-
ing
Alarm Source 6.19
alarm status, indicator light 2.2
Alarm Type 6.19
Alternate Control 6.17, 7.15
ambient temperature 3.3
Analog Input 2 Menu 6.13
Analog Input 3 Menu 6.15 – 6.16
Analog Input x (1 to 3) Menu 6.12 –
6.15
wiring 8.6 – 8.8
Analog Range 6.20
Auto/Manual Key 2.2
Auto/Manual Light 2.2
Auto/Manual Slidewire Calibration
6.15
automatic and manual operation 2.3
Autotune PID 3.1 – 3.2, 6.4,7.9
Autotune PID Menu 6.4
Autotune PID Type 6.4
Autotune Set Point 6.11
autotuning 3.1 – 3.2, 7.9
lockout 6.26
multiple PID sets 3.3
PID 3.1 – 3.2
set point value 3.2, 7.9
Autotuning Channel x (1 or 2) 6.2
B
Baud Rate 6.20
B&B Converter 8.13
boost cool 7.12
Boost Delay Time 6.8
boost heat 7.12
boost on delay 7.12
Boost Power 6.8, 7.12
Boost Power Mode 6.18
Boost Set Point 6.8
Boost Set Point Type 6.19
Boost Type 6.18
burst fire 7.8
heater life 7.8
noise generation (RFI) 7.8
sine wave 7.8
C
Calibrate Input x (1 to 3) Menu 6.27 –
6.28
Calibrate Output x (1A or 1B) and Re-
transmit x (1 and 2) Menu 6.28 –
6.29
Calibration Offset Value 6.14
calibration offset — see multiple input
offsets
Calibration Retransmit x (1 or 2) Menu
6.30 – 6.31
calibration, overview 5.3
inputs 5.3 – 5.4
outputs 5.5 – 5.6
Cascade 6.16
Cascade High Deviation 6.16
Cascade High Range 6.16
Cascade Inner Loop 6.4
Cascade Low Deviation 6.16
Cascade Low Range 6.16
Cascade Outer Loop 6.4
