Watlow F4P Series

Watlow Series F4P Parameters ■ 6.19
✔ Note: For more information about how parameter settings affect the controller’s operation, see the Features Chapter.
Setup Page Parameter Table Modbus
Register
Range read/write Conditions for
Parameter Description (Modbus Value) Default (I/O, Set) Parameters to Appear
Active if Alarm Output is en-
abled.
Output
708 [1]
725 [2]
r/w
Yes on Main
Page (0)
Yes on Main Page (0)
No (1)
Alarm Messages
Select the alarm mes-
sage option.
Active if Alarm Output is en-
abled.
Output
707 [1]
724 [2]
r/w
Open on
Alarm (0)
Open on Alarm (0)
Close on Alarm (1)
Alarm Logic
Select the alarm logic
option.
Active if Alarm Output is en-
abled.
Output
706 [1]
723 [2]
r/w
Both (0)Both (0)
Low (1)
High (2)
Alarm Sides
Choose to enable Low,
High or both alarm set
points.
Active if Alarm Output is en-
abled. Based on decimal set-
ting.
Output
703 [1]
720 [2]
r/w
31 to 30000
0.1 to 30000
0.01 to 30000
0.001 to 30000
(1 to 30000) in integer,
tenths, hundredths,
thousandths
Alarm Hysteresis
Set the alarm
hysteresis.
Active if Alarm Output is en-
abled.
Output
705 [1]
722 [2]
r/w
No (0)No (0)
Yes (1)
Silencing
Choose whether to mask
alarms on power-up.
Active if Alarm Output is en-
abled.
Output
704 [1]
721 [2]
r/w
Alarm Self-
Clears (0)
Alarm Self-Clears (0)
Alarm Latches (1)
Latching
Choose automatic or
manual clearing of
alarms.
Active if the source is enabled.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _)
Output
716 [1]
733 [2]
r/w
Input 1 (0)Input 1 (0)
Input 2 (1)
Input 3 (2)
Alarm Source
Select the alarm source.
Active: Always.
Output
702 [1]
719 [2]
r/w
Off (0)Off (0)
Process (1)
Deviation (2)
Maximum Rate (3)
Alarm Type
Select the alarm type.
Active: Always.
3200-3209 [1]
3210-3219 [2]
r/w
ALARMX<10 characters selected
by user>
Name
Name the alarm for easy
reference.
Main > Setup > Alarm Output x (1 and 2)
Alarm Output x (1 and 2)
