Watlow F4P Series

6.18 ■ Parameters Watlow Series F4P
* Note: Digital inputs are edge triggered and require a transition from a
high to low or low to high state.
✔ Note: Press the Information Key ˆ for more task-related tips.
Setup Page Parameter Table Modbus
Register
Range read/write Conditions for
Parameter Description (Modbus Value) Default (I/O, Set) Parameters to Appear
Setup Page Parameter Table Modbus
Register
Range read/write Conditions for
Parameter Description (Modbus Value) Default (I/O, Set) Parameters to Appear
Active if Boost Type is set to Set
Point.
882 r/w
ProcessProcess (0)
Deviation (1)
Boost Set Point Type (1B)
Select which type of set
point will control output
1B.
Active if Boost Type is set to
Power.
881 r/w
Boost AutoAuto Only (0)
Auto/Manual (1)
Boost Power Mode (1B)
Select whether boost
power operates in Manu-
al Mode.
Active if the control output func-
tions are both set to heat or
cool.
885 r/w
PowerBoost on Power (0)
Boost on Set Point (1)
Boost Type (1B)
Select what will activate
control output 1B.
Active: Always.
Output
715 [1A]
732 [1B]
r/w
0%0% to High Limit -1
( )
Low Power Limit
Set low limit control
(PID mode only) output
power level.
Active: Always.
Output
714 [1A]
731 [1B]
r/w
100%Low Limit +1 to 100%
( )
High Power Limit
Set high limit control
(PID mode only) output
power level.
Active if output 1A is a process
output.
844 r/w
OffOff (0)
On (1)
Duplex (1A)
Control both heat and
cool from one output.
Active if the controller is
equipped with a process output.
Output
701 [1A]
718 [1B]
r/w
4 to 20mA4 to 20mA (0)
0 to 20mA (1)
0 to 5V (2)
1 to 5V (3)
0 to 10V (4)
20 to 4mA (5) [reverse
value]
Process
Set process output type.
Active if Cycle Time Type is set
to Fixed Time.
Output
506 [1A]
556 [1B]
1 second0.1 to 60 seconds
(1 to 600) in tenths
Cycle Time Value
Select the cycle time pe-
riod.
Active if output x is not a me-
chanical relay or process out-
put.
Output
509 [1A]
559 [1B]
r/w
Fixed TimeVariable Burst (0)
Fixed Time (1)
Cycle Time Type
Select the time base.
Active: Always.
Output
700 [1A]
717 [1B]
r/w
Heat (1A)
Off (1B)
Off (0) [1B only]
Heat (1) [reverse]
Cool (2) [direct]
Function
Select type of function
for output.
Main > Setup > Control Output x (1A and 1B)
Control Output x (1A and 1B)
Active: Always.
Input
1061 [1]
1063 [2]
1065 [3]
1067 [4]
r/w
LowLow (0)
High (1)
Condition*
Select the condition to
trigger digital input.
