Watlow Series F4P Parameters ■ 6.17
✔ Note: For more information about how parameter settings affect the
controller’s operation, see the Features Chapter.
Setup Page Parameter Table Modbus
Register
Range read/write Conditions for
Parameter Description (Modbus Value) Default (I/O, Set) Parameters to Appear
Active if Function is set to
Activate Message.
Digital
Input
3060 [1]
3061 [2]
3062 [3]
3063 [4]
r/w
10 seconds0 to 999
(0 to 999)
Message Display Time
Set the length of time
that the message will
display.
Active if Function is set to
Activate Message. (See Main >
Setup > Static Message.)
Digital
Input
3050 [1]
3051 [2]
3052 [3]
3053 [4]
r/w
Message 1 NameMessage1_Name (0)
Message2_Name (1)
Message3_Name (2)
Message4_Name (3)
Activate Message
Select which static mes-
sage to display.
Active if Function is set to
Digital Set Point.
ASCII Digital
Storage Input
3000-3006 [1]
3010-3016 [2]
3020-3026 [3]
3030-3036 [4]
r/w
DGT SP1
DGT SP2
DGT SP3
DGT SP4
<7 characters selected
by user>
Name Digital SP (0)
Name Digital SP (1)
Name Digital SP (2)
Name Digital SP (3)
Name
Name the digital set
point, digital ratio value
or digital differential
value for easy reference.
Active: Always.
Only the currently active fea-
tures will appear in the list.
Input
1060 [1]
1062 [2]
1064 [3]
1066 [4]
r/w
OffOff (0)
Panel Lock (1) [level]
Reset Alarm 1 (2) [edge]
Reset Alarm 2 (3) [edge]
Reset Both Alarms (4)
[edge]
Control Outputs Off (5)
[level]
Digital Set Point (6)
[level]
Digital Differential
Value (7) [level]
Digital Ratio Value (8)
[level]
Remote [set point ana-
log input] 2 (9) [level]
Remote [set point ana-
log input] 3 (10)
[level]
Alternate Control (11)
[level]
Manual Control (12)
[level]
Reverse Outputs (13)
[level]
Activate Message (14)
[edge]
Auto/Manual Key Lock
(15) [level]
Switch PID Sets 1-5
(16) [level]
Function
Select the digital input
function.
Level detect requires
continuous contact
switch.
Edge detect requires
mounting contact switch.
Main > Setup > Digital Input x (1 to 4)
Digital Input x (1 to 4)
