Watlow Series F4P Introduction ■ 1.1
1
Chapter One: Introduction
Inputs and Outputs
Figure 1.1 — Series F4P Inputs and Outputs (Standard, 1 input, F4P _ - _ _ AA - _ _ _ _; and Enhanced, 3 inputs, F4P _ -
_ _ AB - _ _ _ _ ).
2 Control Outputs
2 Alarm Outputs
2 Retransmit Outputs
(optional)
F
4
1
2
ˆ
1B
1A
…Alarm1 Lo Deviation
Adjusts Value
Back Next
–1
F
1 or 3 Universal Analog Inputs
1 Communication Input/Output
4 Digital Inputs
å
Watlow’s Series F4P, 96mm by 96mm (1/4 DIN)
Temperature/Process controllers are easy to set up, pro-
gram and operate in the most demanding applications.
The F4P Temperature/Process controller includes:
• four-line, high resolution LCD display;
• guided setup software;
• context-sensitive information key;
• 16-bit microprocessor;
• universal and digital inputs.
