Watlow PM LEGACY™ Limit Controller • 118 • Appendix
Ordering Information for Limit Controller Models
DRAFT
PM LEGACY Limit Model Configuration Information
① ②
PM
③
Package
Size
④
Primary
Functions
⑤
Power
Supply,
Digital I/O
⑥ ⑦
Output 1 and
2 Hardware
Options
⑧
Comm.
Options
⑨
Future
Option
A
⑫
Model
Selection
⑬ ⑭
Custom
Options
⑩ ⑪
Output 3 and
4 Hardware
Options
③
Package Size
3 =
1
/32 DIN (coming soon)
6 =
1
/16 DIN
⑤
Power Supply, Digital Inputs/Outputs (I/O)
1 =
100 to 240VAC
2 = 100 to 240VAC plus 2 digital I/O points (Not available on
Express version)
3 = 20 to 28VAC or 12 to 40VDC
4 = 20 to 28VAC or 12 to 40VDC, plus 2 digital I/O points (Not
available on Express version)
⑥
Output 1 and 2 Hardware Options
Output 1 Output 2
AJ = None Mechanical relay 5A, Form A
CJ = Switched dc/open collector Mechanical relay 5A, Form A
EJ = Mechanical relay 5A, Form C Mechanical relay 5A, Form A
⑦
⑧
Communication Options
Standard bus always included
A =
None
B = Bluetooth®
E = EIA-485 Modbus® RTU and Bluetooth® (Not available on
Express version)
F = Modbus® RTU 232/485 and Bluetooth® (Not available on
PM3 or Express version)
G = EtherNet/IP™/Modbus® TCP and Bluetooth® (Not available
on PM3 or Express version)
H = DeviceNet™ and Bluetooth® (Not available on PM3 or
Express version)
J = PROFIBUS DP and Bluetooth® (Not available on PM3 or
Express version)
1 = EIA-485 Modbus® RTU (Not available on Express version)
2 = EIA-232/485 Modbus® RTU (Not available on PM3 or Express
version)
3 = EtherNet/IP™/Modbus® TCP (Not available on PM3 or
Express version)
5 = DeviceNet™ (Not available on PM3 or Express version)
6 =
PROFIBUS DP
(Not available on PM3 or Express version)
Note: Bluetooth® not available in all countries, contact factory.
④
Primary Functions
L = Limit controller with universal input
M =
Limit controller with thermistor input
⑩
Output 3 and 4 Hardware Options
Output 3 Output 4
AA = None None
AJ = None Mechanical relay 5A, Form A
AK = None SSR Form A, 0.5 A
CA = Switched dc/open collector None
CC = Switched dc/open collector Switched dc
CJ = Switched dc/open collector Mechanical relay 5A, Form A
CK = Switched dc/open collector SSR Form A, 0.5 A
EA = Mechanical relay 5A, Form C None
EC = Mechanical relay 5A, Form C Switched dc
EJ = Mechanical relay 5A, Form C Mechanical relay 5A, Form A
EK = Mechanical relay 5A, Form C SSR Form A, 0.5A
FA = Universal process None
FC = Universal process Switched dc
FJ = Universal process Mechanical relay 5A, Form A
FK = Universal process SSR Form A, 0.5A
KK = SSR Form A, 0.5A SSR Form A, 0.5A
Note: Only available on
1
/ 16 DIN models if communication Options F,
G, H, J or 2 thru 6 is ordered in previous digit, then Option AA must
be ordered here.
⑪
⑫
Model Selection
G = PM LEGACY Version (Output 1 and 2 always isolated)
H = PM LEGACY EXPRESS Version (Available in PM3 or PM6)
(Output 1 and 2 always isolated)
⑬
Custom Options
WP = Watlow logo face plate
WN =
No logo/no name face plate
AG =
Conformal coating
⑭
Watlow® and EZ-ZONE® are registered trademarks of Watlow Electric Manufacturing
Company.
SMOOTH-TOUCH™ and EZ-LINK™ are trademarks of Watlow Electric Manufacturing
Company.
UL® and cUL® are registered trademarks of Underwriter’s Laboratories, Inc.
i-Phone® is a registered trademark of Apple Corporation.
Android™ is a trademark of Google LLC.
To be automatically connected to the nearest
North American Technical Sales O ce:
1-800-WATLOW2 • www.watlow.com
International Technical Sales Offices:
Austria +43 6244 20129 0
China +86 21 3532 8532
France +33 1 41 32 79 70
Germany +49 7253 9400 0
India +91 40 6661 2700
Italy +39 02 458 8841
Japan +81 3 3518 6630
Korea +82 2 2169 2600
Mexico +52 442 256 2200
Singapore +65 6773 9488
Spain +34 91 675 1292
Taiwan +886 7 288 5168
UK +44 115 964 0777
