Watlow PM LEGACY™ Limit Controller • 79 • Chapter 7 Factory Page
Factory Page
Display
Parameter Name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
In-
stance
Attri-
bute
hex
(dec)
Pro-
fibus
In-
dex
Param-
eter
ID
Data
Type
and Ac-
cess **
diag
FCty
Diagnostics Menu
Pn
Pn
Diagnostics
Part Number
Display this
controller's part
number.
15 characters - - - - - - - - 0x65
(101)
1
9
115 1009 string
R
rEu
rEu
Diagnostics
Software Revi-
sion
Display this con-
troller's firmware
revision number.
1 to 10 - - - - Instance 1
Map 1 Map 2
4 4
0x65
(101)
1
3
116 1003 string
R
S.bLd
S.bLd
Diagnostics
Software Build
Number
Display the firm-
ware build num-
ber.
0 to 2,147,483,647 - - - - Instance 1
Map 1 Map 2
8 8
0x65
(101)
1
5
- -
- -
1005 dint
R
Sn
Sn
Diagnostics
Serial Number
Display the serial
number.
0 to 2,147,483,647 - - - - Instance 1
Map 1 Map 2
12 12
0x65
(101)
1
0x20
(32)
- -
- -
1032 string
R
dAtE
dAtE
Diagnostics
Date of Manu-
facture
Display the date
code (YYWW).
Where YY = year
and WW= week.
0 to 2,147,483,647 - - - - Instance 1
Map 1Map 2
14 14
0x65
(101)
1
8
- -
- -
1008 dint
R
No Dis-
play
Diagnostics
Hardware ID
Display the
Hardware ID.
0 to 2,147,483,647 - - - - Instance 1
Map 1Map 2
0 0
0x65
(101)
1
1
- -
- -
1001 dint
R
No Dis-
play
Diagnostics
Firmware ID
Display the Firm-
ware ID.
0 to 2,147,483,647 - - - - Instance 1
Map 1Map 2
2 2
0x65
(101)
1
2
- -
- -
1002 dint
R
iP.aC
iP.AC
Diagnostics
IP Address Mode
Actual address
mode (DHCP or
Fixed).
dhCP DHCP (1281)
F.Add Fixed Address
(1284)
DHCP - - - - - - - - - -
- -
17013 - - - -
** R: Read, W: Write, E: EEPROM, S: User Set
