Watlow PM LEGACY™ Limit Controller • 54 • Chapter 6 Setup Page
Setup Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP -
Class
In-
stance
Attri-
bute
hex
(dec)
Pro-
fibus
Index
Pa-
rame-
ter
ID
Data
Type
and
Ac-
cess
**
ain
Ain
Analog Input
Analog Input Value
View the process val-
ue.
Note:
Ensure that the Error
Status (below) indi-
cates no error (61)
when reading this
value using a field bus
protocol. If an error
exists, the last known
value prior to the error
occurring will be re-
turned.
-1,999.000 to
9,999.000°F or
units
-1,128.000 to
5,537.000°C
- - - - Instance 1
Map 1 Map 2
360 360
0x68
(104)
1
1
0 4001 float
R
i.Er
i.Er
Analog Input
Input Error
View the cause of the
most recent error.
nonE None (61)
OpEn Open (65)
shrt Shorted
(127)
E.ЛЏ Measurement
Error (140)
E.CaL Bad Calibra-
tion Data (139)
Er.ab Ambient Er-
ror (9)
E.rtd RTD Error
(141)
faiL Fail (32)
- - - -
Instance 1
Map 1 Map 2
362 442
0x68
(104)
1
2
1 4002 uint
R
dio
sEt
Digital Input/Output Menu
dir
dir
Digital Input/Output (5
to 6)
Direction
Set this function to
operate as an input or
output.
otpt Output (68)
in Input Voltage
(193)
iCon Input Dry
Contact (44)
Output Instance 5
Map 1 Map 2
1000 1120
Offset to next
instance
(Map 1 & Map
2) equals +30
0x6A
(106)
5 to 6
1
82 6001 uint
RWES
** R: Read, W: Write, E: EEPROM, S: User Set
