Watlow PM LEGACY™ Limit Controller • 43 • Chapter 5 Operations Page
5
Chapter 5: Operations
Ai
opEr Analog Input Menu
1
Ai Analog Input (1 to 2)
Ain Analog Input Value
i.Er Input Error
i.CA Calibration Offset
dio
opEr Digital Input/Output Menu
1
dio Digital Input/Output (5 to 6)
do.S Output State
di.S Input State
Ei.s Event Status
LiЛЏ
opEr Limit Menu
1
LiЛЏ Limit
LL.S Low Limit Set Point
Lh.S High Limit Set Point
LCr Clear Limit
L.St Limit Status
aLЛЏ
opEr Alarm Menu
1
aLЛЏ Alarm (1 to 4)
A.Lo Low Set Point
a.hi High Set Point
a.CLr Clear Alarm
a.Sir Silence Alarm
a.st Alarm State
PM Operation Page Parameters
To navigate to the Operations Page, follow the steps below:
1. From the Home Page, press both the Up and Down keys for three seconds. Ai will appear in
the red display and oPEr will appear in the green display.
2. Press the Up or Down key to view available menus.
3. Press the Advance Key to enter the menu of choice.
4. If a sub-menu exists (more than one instance), press the Up or Down key to select and then
press the Advance Key to enter.
5. Press the Up or Down key to move through available menu prompts.
6. Press the Reset Key to move backwards through the levels: parameter to sub-menu, sub-menu to
menu, menu to Home Page.
7. Press and hold the Reset Key for two seconds to return to the Home Page.
On the following pages, top level menus are identified with a yellow background color.
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See
model number information in the Appendix for more information. If there is only one instance of a
menu, no sub-menus will appear.
Note:
Some of the listed parameters may not be visible. Parameter visibility is dependent upon controller
part number.
