Watlow PM LEGACY™ Limit Controller • 44 • Chapter 5 Operations Page
Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fib-
us
In-
dex
Pa-
ram-
eter
ID
Data
Type
and
Ac-
cess
**
Ai
opEr
Analog Input Menu
Ain
Ain
Analog Input
Analog Input Value
View the process
value.
Note:
Ensure that the In-
put Error (below) in-
dicates no error (61)
when reading this
value using a field
bus protocol. If an
error exists, the last
known value prior to
the error occurring
will be returned.
-1,999.000 to
9,999.000°F or
units
-1,128.000 to
5,537.000°C
- - - - Instance 1
Map 1 Map 2
360 360
0x68 (104)
1
1
0 4001 float
R
i.Er
i.Er
Analog Input
Input Error
View the cause of
the most recent
error. If the attn
message is Er.i1,
this parameter will
display the cause of
the input error.
Er.i1 = input 1
Er.i2 = input 2
nonE None (61)
OpEn Open (65)
shrtShorted (127)
E.M Measurement
Error (140)
E.CaL Bad Calibra-
tion Data (139)
Er.ab Ambient Er-
ror (9)
E.rtd RTD Error
(141)
faiL Fail (32)
Nsrc Not Sourced
(246)
- - - - Instance 1
Map 1 Map 2
362 362
0x68 (104)
1
2
1 4002 uint
R
i.Ca
i.CA
Analog Input
Calibration Offset
Offset the input
reading to compen-
sate for lead wire
resistance or other
factors that cause
the input reading to
vary from the actual
process value.
-1,999.000 to
9,999.000°F or
units
-1,110.555 to
5,555.000°C
0.0 Instance 1
Map 1 Map 2
382 382
0x68 (104)
1
0xC (12)
2 4012 float
RWES
** R: Read, W: Write, E: EEPROM, S: User Set
