Watlow PM LEGACY™ Limit Controller • 49 • Chapter 6 Setup Page
6
Chapter 6: Setup Page
Navigating the Setup Page
To navigate to the Setup Page follow the steps below:
1. From the Home Page, press and hold both the Up or Down keys for six seconds. Ai will
appear in the red display and SEt will appear in the green display. If the up and down arrow keys are
released where opEr appears in the green display, simply press and hold those same keys for an
additional 3 seconds.
2. Press the Up or Down key to view available menus.
3. Press the Advance Key to enter the menu of choice.
4. If a sub-menu exists (more than one instance), press the Up or Down key to select and then
press the Advance Key to enter.
5. Press the Up or Down key to move through available menu prompts.
6. Press the Reset Key to move backwards through the levels: parameter to sub-menu, sub-menu to
menu, menu to Home Page.
7. Press and hold the Reset Key for two seconds to return to the Home Page.
On the following pages, top level menus are identified with a yellow background color.
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See
model number information in the Appendix for more information. If there is only one instance of a
menu, no sub-menus will appear.
Note:
Some of the listed parameters may not be visible. Parameter visibility is dependent upon controller
part number.
Ai
sEt Analog Input Menu
1 P.EE
Process Error Enable
Ai
Analog Input (1 to 2)
P.EL
Process Error Low Value
sEn
Sensor Type
t.C
Thermistor Curve
Lin
TC Linearization
r.r
Resistance Range
rt.L
RTD Leads
fiL
Filter
Unit
Units
i.Er
Input Error Latching
s.Lo
Scale Low
dEC
Display Precision
s.hi
Scale High
i.Ca
Calibration Offset *
r.Lo
Range Low
ain
Analog Input Value *
r.hi
Range High
i.Er
Input Error *
* These parameters/prompts are available with firmware revisions 11.0 and
above.
gLbL
sEt Global Menu
gLbL
Global
C_f
Display Units
aC.Lf
AC Line Frequency
C.LEd
Communications LED Action
2onE
Zone
d.prs
Display Pairs
d.ti
Display Time
Usr.s
Save Settings As
Usr.r
Restore Settings From
