32 PB0379:m-505atex-en-04
16 Materials of construction
Description Material Finish
Spindle - roller (knurled)* Stainless steel 303S31
Rotor Aluminium HP30TF Anodised
Cradle - extrusion *
Cradle - extrusion
Aluminium 6063 Painted
Track - extrusion Aluminium 6063 Anodised
Rod - locking Stainless steel 303S31
Spacer - locking rod Nylatron GS
Lever - locking rod Stainless steel 303S31
Shaft- drive Stainless steel 303S31
Shaft- drive (505LXA) Stainless steel 303S31
Plate - front Aluminium 5083 Painted
Plate - rear Aluminium 5083 Painted
Cover - adaptor Aluminium 5083 Painted
Plate - end Aluminium 5083 Painted
Tube - guide Stainless steel 303S31
Spring Stainless steel
Ball bearings - roller spindles Carbon steel
Ball bearings - drive shaft Carbon steel
Foot Nylatron and rubber
Screws Stainless steel
Washers Nylon or stainlesssteel
Side assembly (505LXA) Aluminium 6063 and stainless 302S26 Painted
Adaptor assembly Speedal 2011 Painted
The above materials have been carefully selected and have a well proven track record. However, if there
are any aggressive chemicals present then it is imperative that a risk assessment is conducted. This must
not be limited to just the pumped fluid but should also include any other aggressive fluids in the
intended operating environment.
