8
Mixed Outlet
Pressure Sensor (P1)
Recirc Pressure
Sensor (P2)
Cold Pressure
Sensor (P3)
Hot Pressure
Sensor (P4)
-
+
G
Optional Modbus
®
BAS Connection
R
C
12 4
RCCom
0-10
ActFB
53
Mtr
6
78911121310
FT1 Cs F2 +5V
Not Used
Gnd
1514
20 VF1
(dc)Sup
Ret V
4-20
BACnet
26
27 28 29 30 31 32 33 34
35 36 37 38
CsCs CsT1+5V+5V+5V+5V P4P3
T2 T3
P1 P2
2523 2422
ComCom ComCom
21
39 40
Cs
T4
18 19
Gnd
RS-485
20
+
16 17
Alert
Relay
L
G
N
Recirculation
Pump
115 V (ac)
Power Supply
43 44 45 46
NN
L
Power
Pmp
Recirc Return
Flow Sensor (F2)
Mixed Outlet
Flow Sensor (F1)
Mixed Outlet Temperature
Sensor (T1)
Mixed Outlet Fast
Temperature Sensor
Recirc Return Temperature
Sensor (T2)
Cold Supply Temperature
Sensor (T3)
Hot Supply Temperature
Sensor (T4)
Actuator
Motor
Optional BACnet
®
IP
Connection
Alert Relay
1
8
2
RJ45
F1 Gnd +5 V
Sup V
Control Unit Connections (interior)
