Description of Controls and Functions
Programming Menu
Unlock Function
Also shown on the Home screen is the Pump Status Field (showing if pump is ON or OFF), and the
icon to access the Programming menu.
Touching the icon takes the user to the “Programming” Menu containing six function icons –
“Unlock,” “Setup,” “Monitor,” “Sanitize,” “Home” and “Toolbox” – as shown below:
On the “Programming” Menu the and icons are the only active icons until the control is
unlocked. See “Unlock the System” in the “Set up and Programming” section of this Manual.
Touching the icon takes the user back to the Home Screen.
Touching the icon takes the user to the “Unlock” function screen shown below:
UNLOCK SETUP MONITOR
SANITIZE HOME TOOLBOX
Programming
Unlock
Back Clear Enter
?
1
6
2
7
3
8
4
9
5
0
