Watts Powers IntelliStation User Manual

30
Set up and Programming
1. From the “Programming” Menu, touch the icon to go to the System Setup Menu:
1. From the “Programming” Menu, touch the icon to go to the System Setup Menu:
Accessing other settings on the System Setup Menu
The System Set up menu options are as follows:
Menu Options Description
System Setup
BAS Setpoint Max Maximum mixed outlet temperature the BAS system can set
Mixed Outlet Setpoint Mixed outlet temperature setting
High Temp Alert Temperature at which the control will issue a reset (min. 10°F above setpoint).
Pump Operation
Pump setting. AUTO is temperature and pressure based pump control. ON, pump is
always ON. OFF, pump is always OFF.
Pump Head If pressure across the pump is greater than input value, pump will remain OFF
Pump Min On/Off Time The minimum time the pump remains on or off
Return Target Designated temperature of return line water from facility
Return Differential
Designated temperature delta to turn “on” recirculation pump should return line
temperature fall below this value
BAS Setpoint Max
140°F
Mixed Out Setpoint
140°F
Pump Operation
Auto
Pump Min On/Off Time
1 min
High Temp Alert
150°F
Pump Head
0.0 psi
Return Target
130°F
Return Differential
Back Up Down
System
Enter
?
10°F
