Scheduled Testing, Inspection and Maintenance
Maintenance
■ Actuator and/or Valve Removal
■ Actuator Removal Instructions
Valves and actuators are not field serviceable. They must be removed and replaced.
NOTICE
BEFORE attempting to open Control
Module, a certified and qualified elec-
trician MUST fully de-energize and
disconnect all electrical power from
IntelliStation
®
.
Perform required LOCK OUT/TAG OUT
procedures.
When done, reconnection and reenergiz
-
ing of IntelliStation
®
MUST
be performed
by certified and qualified electrician.
DANGER
!
Tools Required:
• 10mm and 3/8" sockets, elbow and torque wrench. Not required if replacing both valve and actuator
• 3/8" wrench. Not required if replacing both valve and actuator
• 2.5mm Allen key. Not required if replacing both valve and actuator
• 1/8" (3.2mm, #2) slot screwdriver. Not required for valve only replacement
• Wire Stripper and snips. Not required for valve only replacement
• AC Voltmeter. Not required for valve only replacement
• Five to ten 4" zap straps (cable ties)
• 4" monkey wrenches (gas grips)
• 3" adjustable wrenches (shifting spanner)
• Teflon Tape. Not required for actuator only replacement
