Description of Controls and Functions
Monitor Function
The Monitor Function allows access to the following fields:
Touching the icon on the “Programming” Menu will allow access to the Monitor Function:
Item Field Range
When is it
Displayed
Description Additional Info
Current Error Always The highest priority error code.
Mixed Outlet
High
-22 to 266°F Always
The highest measured mixed outlet
temperature since last cleared.
Mixed Outlet
Low
-22 to 266°F Always
The lowest measured mixed outlet
temperature since last cleared.
Recirc Pump 0-65535 hrs Always
Accumulated run time hours of pump
since last cleared.
Hot Inlet High -22 to 266°F Always
The highest measured hot inlet
temperature since last cleared.
Hot Inlet Low -22 to 266°F Always
The lowest measured hot inlet
temperature since last cleared.
Pressure High 0-65535 psi Always
psi or kPa
The highest measured DHW outlet
pressure since last cleared.
Resolution in tenths
Pressure Low 0-65535 psi Always
psi or kPa
The lowest measured DHW outlet
pressure since last cleared.
Resolution in tenths
Energy
0-65535 Therms
or GJ
Optional F1 and F2 Flow
Sensors present
The accumulated energy usage since
last cleared.
System Supply Sensor
present
System Return Sensor
present
Flow High 0-65535 gpm
Optional F1 and F2 Flow
Sensors present
gpm or m³/h
The largest load flow measured since
last cleared.
Resolution in tenths
Reset All ON<>OFF Always Clear all monitored values to zero.
--- gpm
Mixed Outlet High
109°F
Energy Used
0 MBtu
Hot Inlet High
158°F
Mixed Outlet Low
91°F
Recirc Pump
0 hr
Hot Inlet Low
130°F
Load Flow High
Current Error
---
Back Up Down
System Monitor
Enter
?
