Watts Powers IntelliStation User Manual

15
Description of Controls and Functions
BAS Menu
The BAS Menu selections are generally described in the table below:
Item Field Range Default
When
Displayed
Description Additional Info
BAS Type
NONE <> BAC-IP
<> BAC-MSTP
<> MODBUS
NONE Always
Building Automation
Type:
None = control runs in stand alone.
BAC-IP = control is connected to a
BACnet/IP system.
BAC-MSTP = control is connected to a
BACnet/MS-TP system.
MODBUS = control is connected to a
Modbus system.
BACnet
DEVICE ID
0 to 4194303 1
BAS Type = BAC-IP or
BAC-MSTP
Buttons on screen are
OK, DEL,<–, --> ?
BACnet device ID
BACnet Port 1 to 65535 47808 BAS Type = BAC-IP
Use keypad entry 0
thru 9
BACnet Portkey in BACnet PORT
Buttons on screen are
OK, DEL,<–, -->, ?
Register
Foreign Dev
OFF<>ON OFF BAS Type = BAC-IP
Is a BACnet Device that has an IP
subnet address different from those
comprising the BACnet/IP network.
BBMD TIME OFF, 30 to 65535 OFF
BAS Type = BACnet Time-to-live (Seconds)
BACnet Broadcast Management. A
specified time, extending that time by
periodic (automatic) renewal requests.
Register Foreign Dev
≠ OFF
Use keypad entry 0
thru 9
key in BBMD TIME
Buttons on screen are
OK, DEL,<–, -->, ?
BBMD IP
0.0.0.1 to
255.255.255.255
127.127.127.127
BAS Type = BACnet
Use keypad entry0
thru 9
BACnet Foreign device internet Protocol
address. A numerical label assigned to
the foreign device.
Register Foreign Dev≠
OFF
key in IP Address
Buttons on screen are
OK, DEL,<–, --> ?
BBMD PORT 0 to 65535 47808
BAS Type = BACnet
Use keypad entry 0
thru 9
BACnet Broadcat Management Port.
Register Foreign Dev≠
OFF
key in BBMD PORT
Buttons on screen are
OK, DEL,<–, --> ?
BAC-MSTP
Address
0 to 127 1 BAS Type = BAC-MSTP
Buttons on screen are
OK, DEL,<–, --> ?
Set the MSTP address. Each MSTP
device must have a unique address.
BACnet Baud
Rate
9600, 19K2,
38K4, 57K6,
76K8, 115K2
9600 BAS Type = BAC-MSTP Slider, OK,<–, --> ? BACnet MS/TP baud rate
Modbus
Address
1 to 247 1 BAS Type = MODBUS Radio buttons, OK, ?
Modbus Address:
1 to 247
Modbus Data
Type
RTU <> ASCII RTU BAS Type = MODBUS Slider, OK,<–, --> ?
Modbus Data Type
RTU or ASCII
Modbus baud
Rate
1200, 4800,
9600, 14K4,
19K2, 28K8,
38K4, 57K6, 76K,
115K2
9600 BAS Type = MODBUS Slider, OK,<–, --> ? Modbus baud rate
Modbus Parity
None <> Odd
<> Even
Even Slider, OK,<–, --> ? Modbus Parity type.
