Watts Powers IntelliStation User Manual

5
IntelliStation Description and Specifications
The IntelliStation
®
components
are shown below:
Dimensions
18.90
[480.1]
31.28
[794.5]
50.00
[1270.0]
56.32
[1430.5]
3.08
[78.2]
3.24
[82.2]
7.47
[189.6]
10.65
[270.5]
8.25
[209.6]
4.91
[124.8]
LFIS150 IS SHEET LINE ART
56.00
[1422.4]
61.73
[1568.0]
3.25
[82.6]
2.48
[63.0]
19.93 [506.2]
33.28 [845.3]
8.23
[209.0]
11.80
[299.8]
8.13
[206.4]
5.12
[130.0]
LFIS200 IS SHEET LINE ART
LFIS150 LFIS200
Dimensions are shown ±1/2''
Dimensions in parentheses are in mm
P1
T1
T4
T2
P2
T3P4 P3
FT1
Control Unit
Mixed Outlet
Temp & Pressure
Sensors
Hot Temp
& Pressure
Sensors
Electronically
Actuated Valve
Recirc Temp &
Pressure Sensors
Cold Temp &
Pressure Sensors
Recirculation
Pump
Hot
Water
Inlet
Cold
Water
Inlet
Return
Mixed Water
Outlet
To
Boiler
