Wavetek TETRA MS Test - Page 39

Test results under remote control
IEEE Command String position Result
RESULt1 12345678901234567890
aaaaaaaaa;bbbbb;****
a = TX power (incl. dimension)
b = Freq. error (Hz)
* = Reserved
RESULt2 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = Residual carrier power (%)
b = RMS vector error
c = Peak vector error
* = Reserved
RESULt3 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = Reserved
b = Reserved
c = Frame alignment (symbols)
* = Reserved
RESULt6 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = TX power Min.
b = TX power Max.
c = TX power Avg.
* = Reserved
RESULt7 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = Freq. error (Hz) Min.
b = Freq. error (Hz) Max.
c = Freq. error (Hz) Avg.
* = Reserved
RESULt8 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = Res. carrier power (%) Min.
b = Res. carrier power (%) Max.
c = Res. carrier power (%) Avg.
* = Reserved
RESULt9 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = RMS vector error Min.
b = RMS vector error Max.
c = RMS vector error Avg.
* = Reserved
RESULtA 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = Peak vector error Min.
b = Peak vector error Max.
c = Peak vector error Avg.
* = Reserved
RESULtD 12345678901234567890
aaaaa;bbbbb;ccccc;**
a = Frame algnmt. (symb.) Min.
b = Frame algnmt. (symb.) Max.
c = Frame algnmt. (symb.) Avg.
* = Reserved
10
Measurements TETRA MS Test
10-39
