General Information
2
CFW-11 | 2-11
A - keypad
B - control rack cover
C - CC11 control board
D - FLASH memory module MMF-03
E - control accessory module
F - Anybus-CC accessory module
G - bottom front cover
H - heatsink fan
I - mounting supports (for surface mounting)
J - hoisting eye
K - rear part of the inverter (external part for flange mounting)
L - SRB3 safety stop board
M - shield for the control cables
I
A
B
H
E
F
G
C
D
I
J
K
L
M
Figure 2.5 - CFW-11 main components - frame size H
