5-10 | CFW-11
5.4 BLOCKING PARAMETERS MODIFICATION
To prevent unauthorized or unintended parameters modification, parameter P0000 should be set to a value
different from 5. Follow the same procedures described in Item 5.2.1 P0000 Password Setting on page 5-3.
5.5 HOW TO CONNECT A PC
NOTES!
- Always use a standard host/device shielded USB cable. Unshielded cables may lead to
communication errors.
- Recommended cables: Samtec:
USBC-AM-MB-B-B-S-1 (1 meter).
USBC-AM-MB-B-B-S-2 (2 meters).
USBC-AM-MB-B-B-S-3 (3 meters).
- The USB connection is galvanically isolated from the mains power supply and from other internal
inverter high voltages. However, the USB connection is not isolated from the protective ground (PE).
Use an isolated notebook for the USB connection or a desktop connected to the same protective
ground (PE) of the inverter.
Install the SuperDrive G2 software in order to control the motor speed, and view or edit the inverter parameters
through a personal computer (PC).
Basic procedures for transferring data from the PC to the inverter:
1. Install the SuperDrive G2 software in the PC.
2. Connect the PC to the inverter through an USB cable.
3. Start SuperDrive G2.
4. Choose "Open" and the files stored in the PC will be displayed.
5. Select the file.
6. Use the command "Write Parameters to the Drive".
- All parameters are now transferred to the inverter.
For further information on the SuperDrive G2 software, refer to the SuperDrive manual.
