CFW-11 | 4-3
NOTE!
At the end of the battery useful life, please do not discard batteries in your waste container, but use
a battery disposal site.
Installation:
The keypad can be installed or removed from the inverter with or without AC power applied to it.
The HMI supplied with the product can also be used for remote command of the inverter. In this case, use a
cable with male and female D-Sub9 (DB-9) connectors wired pin to pin (mouse extension type) or a market
standard Null-Modem cable. Maximum length of 10 m (33 ft). It is recommended the use of the M3 x 5.8
standoffs supplied with the product. Recommended torque: 0.5 N.m (4.50 lbf.in).
When the inverter is energized, the display goes into the monitoring mode. For the factory setting, the screen
similar to Figure 4.3 on page 4-4 will be displayed. By setting proper parameters, other variables can be shown
in the monitoring mode or the content of the parameters can be presented as bar graphs or larger characters
as shown in Figure 4.3 on page 4-4.
