11
READ
P006 - Inverter Status
Range: 0 = Ready
1 = Run
2 = Undervoltage
3 = Fault
4 = Self-Tuning
5 = Configuration
6 = DC Braking
7 = Reserved
8 = Fire Mode
Properties: ro
Description:
It indicates one of the possible inverter status. In Figure 11.1 on page 11-3 contains the description of each state,
as well as the indication on the HMI.
11-2 | Micro Mini Drives
