P680 - Logical Status
Range: 0 to FFFF (hexa)
Bit 0 = Reserved
Bit 1 = Run Command
Bit 2 = Fire Mode
Bit 3 to 4 = Reserved
Bit 5 = 2nd Ramp
Bit 6 = Config. Mode
Bit 7 = Alarm
Bit 8 = Running
Bit 9 = Enabled
Bit 10 = Foward
Bit 11 = JOG
Bit 12 = Remote
Bit 13 = Subvoltage
Bit 14 = Reserved
Bit 15 = Fault
Properties: ro
Description:
The inverter status word is unique for all the sources and can only be accessed for reading. It indicates all the
relevant operating status and modes of the inverter. The function of each bit of P680 is described in Table 11.3 on
page 11-6.
Table 11.3: Status word P680
BIT Function Description
0 Reserved -
1 Run Command
0: There was no Run command
1: There was Run command
2 Fire Mode
0: Fire Mode function inactive
1: Fire Mode function active
3 and 4 Reserved -
5 2
nd
Ramp
0: 1
st
acceleration and deceleration ramp by P100 and P101
1: 2
nd
acceleration and deceleration ramp by P102 and P103
6 Config. Status
0: inverter operating in normal conditions
1: inverter in configuration state. It indicates a special condition in which the inverter cannot be
enabled, because it has parameterization incompatibility
7 Alarm
0: inverter is not in alarm state
1: inverter is in alarm state
8 Running
0: motor is stopped
1: inverter is running according to reference and command
9 Enabled
0: inverter is completely disabled
1: inverter is completely enabled and ready to turn the motor
10 Foward
0: motor is running in the reverser direction
1: motor is running in the foward direction
11 JOG
0: JOG function inactive
1: JOG function active
12 Remote
0: inverter in Local mode
1: inverter in Remote mode
13 Undervoltage
0: no undervoltage
1: with undervoltage
14 Reserved -
15 Fault
0: inverter is not in fault state
1: some fault registered by the inverter
11-6 | Micro Mini Drives
