Bits Values
Bit 0
Sleep Mode Active (A750)
0: Inverter is not in the alarm condition
1: It indicates that the PID controller is in the sleep mode (A750)
Bit 1
PID Controller in Manual or Automatic
0: PID controller operating in Manual mode
1: PID controller operating in Automatic mode
Bit 2
Control Process Variable Low (A760)
0: Inverter is not in the alarm condition
1: It indicates that the control process variable (P916) is in low level (A760)
Bit 3
Fault for Control Process Variable Low
Level (F761)
0: Inverter is not in the fault condition
1: It indicates that the inverter switched the motor off due to the control
variable low level (F761)
Bit 4
Control Process Variable High Level (A762)
0: Inverter is not in the alarm condition
1: It indicates that the control process variable (P916) is in high level (A762)
Bit 5
Fault for Control Process Variable High Level
(F763)
0: Inverter is not in the fault condition
1: It indicates that the inverter switched the motor off due to the control process
variable high level (F763)
Bit 6
Reserved
Reserved
Bit 7
Reserved
Reserved
Bit 8
Reserved
Reserved
Bit 9
Reserved
Reserved
Bit 10
Reserved
Reserved
Bit 11
Reserved
Reserved
Bit 12
Reserved
Reserved
Bit 13
Reserved
Reserved
Bit 14
Reserved
Reserved
Bit 15
Reserved
Reserved
P920 - Selection of the Control Setpoint Source
Range: 0 = Control Setpoint via HMI or Communication Networks (P911)
1 = Control Setpoint via Analog Input AI1
2 = Control Setpoint via Analog Input AI2
3 = Control Setpoint via Electronic Potentiometer (EP)
4 = Two Setpoints via Digital Input DI3 (P912 and P913)
5 = Three Setpoints via Digital Inputs DI3 and DI4 (P912, P913 and P914)
6 = Four Setpoints via Digital Inputs DI3 and DI4 (P912, P913, P914 and P915)
Properties: cfg
Description:
This parameter defines the control setpoint source in automatic mode of the PID controller.
