QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P749
(*)
Profibus Write Word#6 0 to 1199 12-7
P750
(*)
Profibus Address 1 to 126 12-7
P751
(*)
Profibus Teleg. Sel. 1 = Std. Teleg. 1
2 = Telegram 100
3 = Telegram 101
4 = Telegram 102
5 = Telegram 103
12-7
P754
(*)
Profibus Baud Rate 0 = 9.6 kbit/s
1 = 19.2 kbit/s
2 = 93.75 kbit/s
3 = 187.5 kbit/s
4 = 500 kbit/s
5 = Not Detected
6 = 1500 kbit/s
7 = 3000 kbit/s
8 = 6000 kbit/s
9 = 12000 kbit/s
10 = Reserved
11 = 45.45 kbit/s
12-8
P770
(*)
Blueooth Device Name 0 to 9999 12-3
P771
(*)
Bluetooth Password PIN 0 to 9999 12-4
P840
(*)
IR Control Command 0 to FFFF (hexa) ro 9-20
P841
(*)
IR Controle Selection 0 = Without Display
1 = With Display
cfg 9-20
P842
(*)
Quick View 1 IR 0 to 959 5-4
P843
(*)
Quick View 2 IR 0 to 959 5-4
P850
(*)
IP Address Config 0 = Parameters
1 = DHCP
cfg 12-8
P851
(*)
IP Address 1 0 to 255 cfg 12-8
P852
(*)
IP Address 2 0 to 255 cfg 12-8
P853
(*)
IP Address 3 0 to 255 cfg 12-8
P854
(*)
IP Address 4 0 to 255 cfg 12-8
P855
(*)
CIDR Sub-net 1 to 31 cfg 12-8
P856
(*)
Gateway 1 0 to 255 cfg 12-8
P857
(*)
Gateway 2 0 to 255 cfg 12-8
P858
(*)
Gateway 3 0 to 255 cfg 12-9
P859
(*)
Gateway 4 0 to 255 cfg 12-9
P860
(*)
MBTCP: Communication Status 0 = Disabled
1 = No connection
2 = Connected
3 = Timeout Error
ro 12-9
P863
(*)
MBTCP: Active Connections 0 to 4 ro 12-9
P865
(*)
MBTCP: TCP Port 0 to 9999 cfg 12-9
P866
(*)
MBTCP: Unit ID 0 to 255 cfg 12-9
P868
(*)
MBTCP: Timeout 0.0 to 999.9 s cfg 12-9
P869
(*)
Master Status EIP 0 = Run
1 = Idle
ro 12-9
P870
(*)
EIP Communication Status 0 = Disabled
1 = No connection
2 = Connected
3 = Timeout in I/O Connection
4 = Duplicated IP
ro 12-9
P871
(*)
EIP Data Profile 0 = ODVA 20/70: CIP Basic Speed
1 = ODVA 21/71: CIP Enhanced Speed
2 to 3 = Reserved
4 = 20/70: Basic Speed + I/O
5 = 21/71: Enhanced Speed + I/O
6 to 7 = Reserved
8 = 100/150: Speed + I/O
9 to 10 = Reserved
cfg 12-10
P872
(*)
Read Word #3 Ethernet 0 to 9999 12-10
P873
(*)
Read Word #4 Ethernet 0 to 9999 12-10
P874
(*)
Read Word #5 Ethernet 0 to 9999 12-10
P875
(*)
Read Word #6 Ethernet 0 to 9999 12-10
P876
(*)
Read Word #7 Ethernet 0 to 9999 12-10
P877
(*)
Read Word #8 Ethernet 0 to 9999 12-10
P880
(*)
Write Word #3 Ethernet 0 to 9999 12-10
0-20 | Micro Mini Drives
