QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P702
(*)
CAN Baud Rate 0 = 1 Mbps/Auto
1 = Reserved/Auto
2 = 500 Kbps
3 = 250 Kbps
4 = 125 Kbps
5 = 100 Kbps/Auto
6 = 50 Kbps/Auto
7 = 20 Kbps/Auto
8 = 10 Kbps/Auto
12-4
P703
(*)
Bus Off Reset 0 = Manual
1 = Automatic
12-4
P705
(*)
CAN Controller Status 0 = Disabled
1 = Auto-baud
2 = CAN Active
3 = Warning
4 = Error Passive
5 = Bus Off
6 = No Bus Power
ro 12-5
P706
(*)
RX CAN Telegrams 0 to 9999 ro 12-5
P707
(*)
TX CAN Telegrams 0 to 9999 ro 12-5
P708
(*)
Bus Off Counter 0 to 9999 ro 12-5
P709
(*)
CAN Lost Messages 0 to 9999 ro 12-5
P710
(*)
DeviceNet I/O instances 0 = ODVA Basic 2W
1 = ODVA Extend 2W
2 = Manuf.Spec.2W
3 = Manuf.Spec.3W
4 = Manuf.Spec.4W
5 = Manuf.Spec.5W
6 = Manuf.Spec.6W
12-5
P711
(*)
DeviceNet Read Word #3 0 to 1199 12-5
P712
(*)
DeviceNet Read Word #4 0 to 1199 12-5
P713
(*)
DeviceNet Read Word #5 0 to 1199 12-5
P714
(*)
DeviceNet Read Word #6 0 to 1199 12-5
P715
(*)
DeviceNet Write Word #3 0 to 1199 12-6
P716
(*)
DeviceNet Write Word #4 0 to 1199 12-6
P717
(*)
DeviceNet Write Word #5 0 to 1199 12-6
P718
(*)
DeviceNet Write Word #6 0 to 1199 12-6
P719
(*)
DeviceNet Network Status 0 = Offline
1 = OnLine, Not Conn
2 = OnLine, Connect.
3 = Connection Timed out
4 = Link Failure
5 = Auto-Baud
ro 12-6
P720
(*)
DeviceNet Master Status 0 = Run
1 = Idle
ro 12-6
P721
(*)
CANopen Comm. Status 0 = Disabled
1 = Reserved
2 = Communic. Enabled
3 = Error Ctrl. Enable
4 = Guarding Error
5 = Heartbeat Error
ro 12-6
P722
(*)
CANopen Node Status 0 = Disabled
1 = Initialization
2 = Stopped
3 = Operational
4 = Preoperational
ro 12-6
P740
(*)
Profibus Comm. Status 0 = Disabled
1 = Access Error
2 = Offline
3 = Config. Error
4 = Param. Error
5 = Clear Mode
6 = Online
ro 12-7
P742
(*)
Profibus Read Word #3 0 to 1199 12-7
P743
(*)
Profibus Read Word #4 0 to 1199 12-7
P744
(*)
Profibus Read Word #5 0 to 1199 12-7
P745
(*)
Profibus Read Word #6 0 to 1199 12-7
P746
(*)
Profibus Write Word#3 0 to 1199 12-7
P747
(*)
Profibus Write Word#4 0 to 1199 12-7
P748
(*)
Profibus Write Word#5 0 to 1199 12-7
