QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P580 Fire Mode Configuration 0 = Inactive
1 = Active
2 = Active / P134
3 = Reserved
4 = Active / General Disable
cfg 8-16
P582 Fire Mode Auto-reset Adjustable 0 = Limited
1 = Unlimited
cfg 8-16
P588 EOC Maximum Torque 0 to 85 % cfg 8-25
P589 EOC Minimum Voltage 40 to 80 % cfg 8-25
P590 EOC Minimum Frequency 12.0 to 400.0 Hz cfg 8-25
P591 EOC Hysteresis 0 to 30 % cfg 8-25
P613 Main SW Revision -9999 to 9999 ro 6-3
P680 Logical Status 0 to FFFF (hexa)
Bit 0 = Reserved
Bit 1 = Run Command
Bit 2 = Fire Mode
Bit 3 to 4 = Reserved
Bit 5 = 2nd Ramp
Bit 6 = Config. Mode
Bit 7 = Alarm
Bit 8 = Running
Bit 9 = Enabled
Bit 10 = Foward
Bit 11 = JOG
Bit 12 = Remote
Bit 13 = Subvoltage
Bit 14 = Reserved
Bit 15 = Fault
ro 11-6
P681 13-Bit Speed 0 to FFFF (hexa) ro 11-7
P682 Serial/USB Control 0 to FFFF (hexa)
Bit 0 = Ramp Enable
Bit 1 = General Enable
Bit 2 = Run Forward
Bit 3 = JOG Enable
Bit 4 = Remote
Bit 5 = 2nd Ramp
Bit 6 = Reserved
Bit 7 = Fault Reset
Bit 8 to 15 = Reserved
ro 12-1
P683 Serial/USB Speed Ref. 0 to FFFF (hexa) ro 12-1
P684
(*)
CO/DN/DP/ETH Control 0 to FFFF (hexa)
Bit 0 = Ramp Enable
Bit 1 = General Enable
Bit 2 = Run Forward
Bit 3 = JOG Enable
Bit 4 = Remote
Bit 5 = 2nd Ramp
Bit 6 = Reserved
Bit 7 = Fault Reset
Bit 8 to 15 = Reserved
ro 12-1
P685
(*)
CO/DN/DP/ETH Speed Ref 0 to FFFF (hexa) ro 12-2
P690 Logic State 2 0 to FFFF (hexa)
Bit 0 to 2 = Reserved
Bit 3 = Energy Saver
Bit 4 = Fs Reduction
Bit 5 = Reserved
Bit 6 = Deceleration Ramp
Bit 7 = Acceleration Ramp
Bit 8 = Freeze Ramp
Bit 9 = Setpoint Ok
Bit 10 = DC Link Regulation
Bit 11 = 50Hz Config
Bit 12 = Ride-Through
Bit 13 = Flying Start
Bit 14 = DC Braking
Bit 15 = PWM pulse
ro 11-7
P695 DOx Value 0 to 127 ro 9-24
P696
(*)
AOx Value 1 0 to FFFF (hexa) ro 9-9
P697
(*)
AOx Value 2 0 to FFFF (hexa) ro 9-9
P700
(*)
CAN Protocol 1 = CANopen
2 = DeviceNet
12-4
P701
(*)
CAN Address 0 to 127 12-4
