QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P311 Serial Bytes Config. 0 = 8 bits, no, 1
1 = 8 bits, even,1
2 = 8 bits, odd, 1
3 = 8 bits, no, 2
4 = 8 bits, even,2
5 = 8 bits, odd, 2
cfg 12-2
P312 Serial Protocol 0 to 1 = Reserved
2 = Modbus RTU Slave
3 to 4 = Reserved
5 = ModBus RTU Master
cfg 12-3
P313 Action for Comminic. Error 0 = Inactive
1 = Ramp Stop
2 = General Disable
3 = Go to LOC
4 = LOC Keep Enab.
5 = Cause Fault
12-3
P314 Serial Watchdog 0.0 to 999.0 s cfg 12-3
P316 Serial Interf. Status 0 = Inactive
1 = Active
2 = Watchdog Error
ro 12-3
P320 Flying Start / Ride-Through 0 = Inactive
1 = Flying Start
2 = FS / RT
3 = Ride-Through
cfg 8-9
P331 Voltage Ramp for FS and RT 0.2 to 60.0 s 8-10
P332 Dead Time 0.1 to 10.0 s 8-10
P340 Auto-Reset Time 0 to 255 s 10-2
P352 Fan Control Config. 0 = OFF
1 = ON
2 = CT
cfg 10-3
P358
(*)
Encoder Fault Config. 0 = Inactive
1 = F067 ON
2 = F079 ON
3 = F067 and F079 ON
cfg 10-3
P375
(*)
NTC Temperature 0 to 200 ºC ro 9-5
P397 Control Config 0 to F (hexa)
Bit 0 = Slip Compens. Regen.
Bit 1 = Dead Time Comp.
Bit 2 = Is Stabilization
Bit 3 = P297 reduction in A050
cfg 8-16
P399 Motor Rated Efficiency 50.0 to 99.9 % cfg, VVW 8-32
P400 Motor Rated Voltage 0 to 480 V cfg, VVW 8-32
P401 Motor Rated Current 0.0 to 40.0 A cfg, VVW 8-32
P402 Motor Rated Speed 0 to 24000 rpm cfg, VVW 8-33
P403 Motor Rated Frequency 0 to 400 Hz cfg, VVW 8-33
P404 Motor Rated Power 0 = 0.16 HP (0.12 kW)
1 = 0.25 HP (0.18 kW)
2 = 0.33 HP (0.25 kW)
3 = 0.50 HP (0.37 kW)
4 = 0.75 HP (0.55 kW)
5 = 1.00 HP (0.75 kW)
6 = 1.50 HP (1.10 kW)
7 = 2.00 HP (1.50 kW)
8 = 3.00 HP (2.20 kW)
9 = 4.00 HP (3.00 kW)
10 = 5.00 HP (3.70 kW)
11 = 5.50 HP (4.00 kW)
12 = 6.00 HP (4.50 kW)
13 = 7.50 HP (5.50 kW)
14 = 10.00 HP (7.50 kW)
cfg, VVW 8-33
P405
(*)
Encoder Pulses Number 32 to 9999 cfg, VVW 8-33
P407 Motor Rated Power Factor 0.50 to 0.99 cfg, VVW 8-24
P408 Run Self-Tuning 0 = No
1 = Yes
cfg, VVW 8-34
P409 Stator Resistance 0.01 to 99.99 cfg, VVW 8-34
P510 SoftPLC Eng. Unit See options in P209 5-3
P511 SoftPLC Indication Form See options in P210 5-4
Micro Mini Drives | 0-17
