QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P275 DO1 Function 0 = Not Used
1 = F* ≥ Fx
2 = F ≥ Fx
3 = F ≤ Fx
4 = F = F*
5 = Not Used
6 = Is > Ix
7 = Is < Ix
8 = Torque > Tx
9 = Torque < Tx
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No F070
15 = Not Used
16 = No F021/F022
17 = Not Used
18 = No F072
19 = 4-20mA OK
20 = P695 Value
21 = Forward
22 to 23 = Not Used
24 = Ride-Through
25 = Pre-Charge OK
26 = Fault
27 = Not Used
28 = SoftPLC
29 to 34 = Not Used
35 = No Alarm
36 = Without fault and alarm
37 = Application Function 1
38 = Application Function 2
39 = Application Function 3
40 = Application Function 4
41 = Application Function 5
42 = Application Function 6
43 = Application Function 7
44 = Application Function 8
45 = Fire Mode ON
46 = Low Level of Process Variable
47 = High Level of Process Variable
9-21
P276
(*)
DO2 Function See options in P275 9-21
P277
(*)
DO3 Function See options in P275 9-21
P278
(*)
DO4 Function See options in P275 9-22
P281 Fx Frequency 0.0 to 400.0 Hz 9-23
P282 Fx Hysteresis 0.0 to 15.0 Hz 9-24
P290 Ix Current 0.0 to 40.0 A 9-24
P293 Tx Torque 0 to 200 % 9-24
P295 Inverter Rated Current 1.1 to 15.2 A ro 6-2
P296 Line Rated Voltage 0 = Reserved
1 = 110 - 127 Vac
2 = 200 - 240 Vac | 310 Vdc
3 = Reserved
4 = 380 Vac | 513 Vdc
5 = 415 Vac | 560 Vdc
6 = 440 Vac | 594 Vdc
7 = 480 Vac | 650 Vdc
cfg 6-3
P297 Switching Frequency 2.5 to 15.0 kHz cfg, V/f, VVW 8-9
P299 DC Braking Start Time 0.0 to 15.0 s V/f, VVW 8-11
P300 DC Braking Stop Time 0.0 to 15.0 s V/f, VVW 8-11
P301 DC Braking Frequency 0.0 to 15.0 Hz V/f, VVW 8-12
P302 DC Braking Current 0.0 to 100.0 % V/f, VVW 8-12
P303 Skip Frequency 1 0.0 to 400.0 Hz V/f, VVW 8-13
P304 Skip Frequency 2 0.0 to 400.0 Hz V/f, VVW 8-14
P306 Skip Band 0.0 to 25.0 Hz V/f, VVW 8-14
P308 Serial Address 1 to 247 cfg 12-2
P310 Serial Baud Rate 0 = 9600 bits/s
1 = 19200 bits/s
2 = 38400 bits/s
cfg 12-2
