FREQUENCY INVERTER IDENTIFICATION
Table 6.1: Identification of the inverter models
Frame Size Voltage Power Supply Current P029
1.6 A 1
2.6 A 2
4.2 A 3
110 / 127 Vca Single-Phase
6.0 A 4
1.6 A 5
2.6 A 6
4.2 A 7
6.0 A 8
200 / 240 Vca Single-Phase or Three-Phase
7.3 A 9
1.6 A 5
2.6 A 6
4.2 A 7
6.0 A 8
A
310 Vdc DC Link
7.3 A 9
Single-Phase or Three-Phase 10.0 A 10
200 / 240 Vca
Three-Phase 15.2 A 11
10.0 A 10
B
310 Vdc DC Link
15.2 A 11
1.1 A 20
1.8 A 21
2.6 A 22
3.5 A 23
A 380 / 480 Vca Three-Phase
4.8 A 24
1.1 A 20
1.8 A 21
2.6 A 22
3.5 A 23
4.8 A 24
6.5 A
(*)
/ 5.6 A
(**)
25
B
8.2 A
(*)
/ 7.6 A
(**)
26
10.0 A
(*)
/ 8.3 A
(**)
27
12.0 A
(*)
/ 11.0 A
(**)
28
C
380 / 480 Vca or 513 to 650 Vdc Three-Phase or DC Link
15.0 A
(*)
/ 14.0 A
(**)
29
(*) Rated current for power supplies of 380-400-415 Vac.
(**) Rated current for power supplies of 440-460-480 Vac.
✓
NOTE!
The models of the 400 V line have rated currents specified according to the supply voltage:
Voltage range 1: power supplies of 380-400-415 Vac, or 513-540-560 Vdc (P296 = 4 or 5).
Voltage range 2: power supplies of 440-460-480 Vac, or 594-621-650 Vdc (P296 = 6 or 7).
For these models, P296 must be adjusted in accordance with the mains voltage used, and the
parameter P295 will be changed automatically by the inverter. For more information, refer to the
user manual, available for download on www.weg.net.
P295 - Inverter Rated Current
Range: 1.1 to 15.2 A
Properties: ro
Description:
This parameter presents the inverter rated current according to Table 6.1 on page 6-2.
