QUICK REFERENCE OF PARAMETERS
Param. Description Adjustable Range Prop. Page
P266 DI4 Input Function 0 = Not Used
1 = Run/Stop
2 = General Enable
3 = Quick Stop
4 = Foward Run
5 = Reverse Run
6 = Start
7 = Stop
8 = Direction of Rotation
9 = LOC/REM
10 = JOG
11 = Accelerate E.P.
12 = Decelerate E.P.
13 = Multispeed
14 = 2nd Ramp
15 to 17 = Not Used
18 = No Ext. Alarm
19 = No Ext. Fault
20 = Reset
21 to 23 = Not Used
24 = Disab.FlyStart
25 = Not Used
26 = Progr. Off
27 to 31 = Not Used
32 = 2nd ramp Multispeed
33 = 2nd ramp Increase EP
34 = 2nd ramp Decrease EP
35 = 2nd ramp FWD Run
36 = 2nd ramp REV Run
37 = Start / Inc. EP
38 = Dec. EP / Stop
39 = Stop
40 = Safety Switch
41 = Application Function 1
42 = Application Function 2
43 = Application Function 3
44 = Application Function 4
45 = Application Function 5
46 = Application Function 6
47 = Application Function 7
48 = Application Function 8
49 = Enable Fire Mode
50 to 51 = Not Used
52 = Command to Decrease the Control
Setpoint (EP)
53 = Not Used
54 = 2nd DI for Control Setpoint Selection
55 = Run/Stop with Line Start Lockout
cfg 9-12
P267
(*)
DI5 Input Function See options in P263 cfg 9-12
P268
(*)
DI6 Input Function See options in P263 cfg 9-12
P269
(*)
DI7 Input Function See options in P263 cfg 9-12
P270
(*)
DI8 Input Function See options in P263 cfg 9-13
P271 DIs Function 0 = (DI1..DI8) NPN
1 = (DI1..DI4) PNP
2 = (DI5..DI8) PNP
3 = (DI1..DI8) PNP
cfg 9-15
