9
I/O
Table 9.5: Digital Input Functions
Value Description Dependence Figure (Page)
0 Not used - -
1 Run/Stop command P224 = 1 or P227 = 1 9.6 (9-15)
2 General Enable command - 9.7 (9-15)
3 Fast Stop P224 = 1 or P227 = 1 9.8 (9-15)
4 Forward run command
(P224 = 1 and P223 = 4) or
(P227 = 1 and P226 = 4)
9.9 (9-16)
5 Reverse run command P224 = 1 or P227 = 1 9.9 (9-16)
6 Start command P224 = 1 or P227 = 1 9.10 (9-16)
7 Stop command P224 = 1 or P227 = 1 9.10 (9-16)
8 Forward Rotation Direction P223 = 4 or P226 = 4 9.11 (9-17)
9 Local/Remote selection P220 = 4 -
10 JOG command
(P224 = 1 and P225 = 2) or
(P227 = 1 and P228 = 2)
9.12 (9-17)
11 Electronic Potentiometer: Accelerate E.P. P221 = 7 or P222 = 7 9.13 (9-18)
12 Electronic Potentiometer: Decelerate E.P. P221 = 7 or P222 = 7 9.13 (9-18)
13 Multispeed reference P221 = 8 or P222 = 8 -
14 2
nd
Ramp selection P105 = 2 9.14 (9-18)
15 to 17 Not used - -
18 No external alarm - -
19 No external fault - -
20 Fault reset Active fault -
21 to 23 Not used - -
24 Disable flying start P320 = 1 or 2 -
25 Not used - -
26 Lock Prog. - -
27 to 31 Not used - -
32 Multispeed reference with 2
nd
Ramp (P221 = 8 or P222 = 8) and P105 = 2 -
33 Electronic Potentiometer: Accelerates E.P. with 2
nd
Ramp (P221 = 7 or P222 = 7) and P105 = 2 -
34 Electronic Potentiometer: Decelerates E.P. with 2
nd
Ramp (P221 = 7 or P222 = 7) and P105 = 2 -
35 Forward run with 2
nd
Ramp
(P224 = 1 and P223 = 4) or
(P227 = 1 and P226 = 4) and P105 = 2
-
36 Reverse run with 2
nd
Ramp
(P224 = 1 and P223 = 4) or
(P227 = 1 and P226 = 4) and P105 = 2
-
37 Accelerates E.P./Start
(P224 = 1 or P227 = 1) and
(P221 = 7 or P222 = 7)
9.15 (9-19)
38 Decelerates E.P./ Stop
(P224 = 1 or P227 = 1) and
(P221 = 7 or P222 = 7)
9.15 (9-19)
39 Stop command P224 = 1 or P227 = 1 9.16 (9-19)
40 Safety switch command P224 = 1 or P227 = 1 9.17 (9-20)
41 Application Function 1 - -
42 Application Function 2 - -
43 Application Function 3 - -
44 Application Function 4 - -
45 Application Function 5 - -
46 Application Function 6 - -
47 Application Function 7 - -
48 Application Function 8 - -
49 Activate Fire Mode - -
50 Manual/Automatic PID (Only DI2 for P903 = 1)
(*)
-
51 Increase Setpoint Command (PE) (Only DI3 for P903 = 1)
(*)
-
52 Decrease Setpoint Command (Only DI4 for P903 = 1)
(*)
-
53 1
st
DI Control Setpoint (Only DI3 for P903 = 1)
(*)
-
54 2
nd
DI Control Setpoint (Only DI4 for P903 = 1)
(*)
-
55 Run/Stop with Line Start Lockout - -
(*) For further details refer the Chapter 14 APPLICATIONS on page 14-1.
9-14 | Micro Mini Drives
