9
I/O
P270 - DI8 Input Function
Range: 0 = Not Used
1 = Run/Stop
2 = General Enable
3 = Quick Stop
4 = Foward Run
5 = Reverse Run
6 = Start
7 = Stop
8 = Direction of Rotation
9 = LOC/REM
10 = JOG
11 = Accelerate E.P.
12 = Decelerate E.P.
13 = Multispeed
14 = 2nd Ramp
15 to 17 = Not Used
18 = No Ext. Alarm
19 = No Ext. Fault
20 = Reset
21 to 23 = Not Used
24 = Disab. Flying Start
25 = Not Used
26 = Lock Prog.
27 to 31 = Not Used
32 = 2nd ramp Multispeed
33 = 2nd ramp Increase EP
34 = 2nd ramp Decrease EP
35 = 2nd ramp FWD Run
36 = 2nd ramp REV Run
37 = Start / Inc. EP
38 = Dec. EP / Stop
39 = Stop
40 = Safety Switch
41 = Application Function 1
42 = Application Function 2
43 = Application Function 3
44 = Application Function 4
45 = Application Function 5
46 = Application Function 6
47 = Application Function 7
48 = Application Function 8
49 = Enable Fire Mode
50 to 54 = Not Used
55 = Run/Stop with Line Start Lockout
Properties: cfg
Description:
These parameters allow configuring the digital input function, according to the adjustable range listed in Table 9.5
on page 9-14.
Micro Mini Drives | 9-13
