7
COMMAND AND REFERENCES
0 - HMI
4 - FI
17 - FI > 0
7 - EP
8 - Multispeed
1 - AI1
14 - AI1 > 0
5 - AI1 + AI2 > 0
6 - AI1 + AI2
2 - AI2
15 - AI2 > 0
9 - Serial/USB
11 - CO/DN/DP/ETH
12 - SoftPLC
HMI
HMIR
DIx
DIx
DIx
DIx
DIx
P249
P247
P232
P234
AI1
P237
P239
AI2
PC
P242
P244
Frequency
reference of
the inverter
Command
selection
frequency
P221 or P222
CRS485
Accessory
Reference
key (P121)
FI
via
DI1 to DI4
Accel.
Decel.
Electronic Potentiometer
P124 to P131
Multispeed
CRS232
Accessory
CUSB
Accessory
CRS485
Accessory
CBLT
Accessory
USB - RS485
Converter
Bluetooth
adapter
CCAN / CPDP / CETH-IP
Accessory
CANopen / DeviceNet
Profibus DP
ModbusTCP / Ethernet-IP
SoftPLC
Potentiometer
3 - Potentiometer
16 - Potentiometer > 0
Figure 7.2: Structure to select the frequency reference
Micro Mini Drives | 7-3
