7
COMMAND AND REFERENCES
P220 - LOC/REM Selection Source
Range: 0 = Always Local
1 = Always Remote
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (LOC)
6 = Serial/USB (REM)
7 to 8 = Not Used
9 = CO/DN/DP/ETH (LOC)
10 = CO/DN/DP/ETH (REM)
11 = SoftPLC
Properties: cfg
Description:
It defines the command origin source which will select between Local situation and Remote situation, where:
LOC: means Local situation default.
REM: means Remote situation default.
DIx: according to function programmed for digital input in P263 to P266.
CO / DN / DP / ETH: interface CANopen, DeviceNet, Profibus DP or Ethernet.
P221 - LOC Reference Sel.
P222 - REM Reference Selection
Range: 0 = HMI
1 = AI1
2 = AI2
3 = Potentiometer
4 = FI
5 = AI1 + AI2 > 0
6 = AI1 + AI2
7 = E.P.
8 = Multispeed
9 = Serial/USB
10 = Not Used
11 = CO/DN/DP/ETH
12 = SoftPLC
13 = Not Used
14 = AI1 > 0
15 = AI2 > 0
16 = Potentiometer > 0
17 = FI > 0
Properties: cfg
Description:
These parameters define the origin source for the frequency reference in the Local situation and Remote situation.
Some comments on the options of this parameter:
AIx: it refers to the analog input signal according to Section 9.1 ANALOG INPUTS on page 9-1.
